Smart phone controlled LED lamp

I was meaning to put this up for quite a while now. Back in 2011, I designed and built a ceiling lamp which I wanted to share.

Goal

It started out when we wanted to improve the lighting situation in our living room and I was initially looking for an off-the-shelf lamp which full fills our needs:

  • potential to provide a lot of light (>8000 lumens for our ~30m^2 room)
  • dimmable
  • indirect lightning
  • minimalistic (& invisible?) design
  • low power (LED)
  • controllable from a computer/smartphone

One would think that in 2011 this kind of lamp would be main stream, but it turned out to be quite hard to find a lamp (or two) which would fit our needs. This is why I started to play with the idea to design and build my own.

Read more

Garage door controller – part 2

The finished PCB has arrived quite a while ago now and has been assembled as well. Time to upload the final part of this project to see some results.

I selected Beta Layout as the PCB manufacturer for this project with quite satisfying results. I especially liked that they sent me automated pictures of the board after each manufacture step, which turned out to be very useful. Using those, I was able to detect that the holes had been drilled using the wrong drill sizes. They recognized this error and produced a new board with the correct hole sizes within the agreed delivery date.

The final board:

Read more

Garage door controller – part 1

In my garage I have a door opener from the norwegian firm Edlandsporten. Here is a picture of the device and the official brochure:



Unfortunately, the included wireless hand transmitter (for the norwegian folks: “extra fjernkontroll”) to open/close the door has broken down and I need a replacement for it. I contacted the manufacture and they offered me a set of two new hand transmitters for a ridiculous  price of  1000 NOK (~ 125 EUR). In my opinion, this is madness for such a cheap piece for hardware. After a short investigation on the Internet, trying to find cheaper alternatives, I decided to build my own and publish the project. This blog entry is the first part of the design and build process of this door controller.

Read more

General purpose RF receiver

In this blog entry, I wrote about my sensor project which transmits it’s measurements via a 433Mhz wireless communication link. On this page I will describe the details of my self built receiver which receives data from this sensor.

Goal

To build a general purpose RF receiver module which receives messages from a 433 Mhz wireless link (for example from my self built RF sensor) and forward the received and decoded message to my Linux server via USB, where they are further processed.

Read more

Landscape of Norway

A selection of photographs which were taken during summer 2009:

Read more
